HONB HRBH11020 Thin Crossed Roller Bearing (110 x 160 x 20 mm)
HONB (Luoyang Hongyuan) · MPN HRBH11020 · Maglev ID ac-honb-hrbh11020
CN Maker in China, factory not confirmed unknown VERIFIED
Large-bore one-piece crossed roller bearing from Luoyang Hongyuan for hip, shoulder or hollow-shaft joints, CRBH11020 equivalent size.
Specifications
| Bore | 110 mm |
|---|---|
| Outside diameter | 160 mm |
| Width | 20 mm |
| Basic dynamic load rating C | 52.4 kN |
| Type | Crossed roller, integral inner and outer rings, ultra-thin (CRBH type) |
| Basic static load rating C0 | 77.4 kN |
Who makes it
MakerLuoyang Hongyuan Bearing Technology Co., Ltd.
Based inChina
RoleFactory
Need a different shaft, connector, firmware or enclosure, or a price at 1,000 units? Maglev takes the catalog part to the factory and comes back with a custom version and one fixed price.
Landed cost in the US
CN
43.3%
TW
10%
VN
18.3%
IN
15.8%
JP
12.5%
KR
12.5%
DE
10%
MX
15.8%
US
0%
Total US duty on this part by where it is made (2026-10-29). Mexico shown before USMCA preference; qualifying goods enter duty free. Your factory choice, not the shipping port, sets the origin.
Loading duty data…
Compliance
| HTS classification | 8482.50.0000 |
|---|---|
| NDAA | unknown |
| Blue UAS | unknown |
| FCC | n/a |
Equivalents from other makers
Sources
- https://www.honb.com/products_show/4.htmlHRBH size table (d, D, B, C, C0, mass), images
Record confidence: VERIFIED. VERIFIED means the maker's own documents; REPORTED means a credible third party; UNVERIFIED means a single weak source. Anything we could not confirm says unknown.
