TI BOOSTXL-DRV8323RS Three-Phase Driver BoosterPack
Texas Instruments · MPN BOOSTXL-DRV8323RS · Maglev ID mo-ti-boostxl-drv8323rs
US Maker in United States, factory not confirmed unknown VERIFIED
15 A three-phase BLDC power stage EVM (DRV8323RS gate driver + CSD88599Q5DC NexFETs) that plugs onto a LaunchPad MCU for FOC/InstaSPIN development.
Specifications
| Bus voltage | 6-54 V |
|---|---|
| Continuous current | 15 A |
| Peak current | 20 A |
| Interface | SPI (gate-driver config); LaunchPad BoosterPack headers |
| Feedback | 3 low-side current shunt amps, DC bus and phase voltage sensing (sensorless) |
| Power stage | CSD88599Q5DC 60 V NexFET power blocks |
Who makes it
MakerTexas Instruments
Based inUnited States
RoleBrand owner
Need a different shaft, connector, firmware or enclosure, or a price at 1,000 units? Maglev takes the catalog part to the factory and comes back with a custom version and one fixed price.
Landed cost in the US
CN
37.5%
TW
10%
VN
12.5%
IN
10%
JP
12.5%
KR
12.5%
DE
10%
MX
10%
US
0%
Total US duty on this part by where it is made (2026-10-29). Mexico shown before USMCA preference; qualifying goods enter duty free. Your factory choice, not the shipping port, sets the origin.
Loading duty data…
Compliance
| HTS classification | 8504.40.40.00 typical, not a ruling |
|---|---|
| NDAA | unknown |
| Blue UAS | unknown |
| FCC | n/a |
| Notes | Board only; needs a TI LaunchPad (e.g. LAUNCHXL-F280025C, listed $35.09 on same page) as controller. |
Works with
Sources
- https://www.ti.com/tool/BOOSTXL-DRV8323RSspecs, docs links, TI.com price $86.90 (data-price attribute)
Record confidence: VERIFIED. VERIFIED means the maker's own documents; REPORTED means a credible third party; UNVERIFIED means a single weak source. Anything we could not confirm says unknown.
