CubeMars GL40 KV70 Gimbal Motor
CubeMars · MPN GL40 KV70 · Maglev ID mo-cubemars-gl40-kv70
CN Maker in China, factory not confirmed unknown VERIFIED
46.5 mm hollow-shaft (8 mm bore) low-cogging gimbal outrunner for camera gimbals, pods and small direct-drive joints.
Specifications
| KV | 63.5 rpm/V measured (model name KV70) |
|---|---|
| Rated voltage | 16 V |
| Peak torque | 0.5 Nm (cubemars.com spec table); store page says stall/peak 0.73 Nm |
| Outer diameter | 46.5 mm |
| Mass | 107 g |
| Rated torque | 0.25 Nm |
| Height | 21.5 mm |
| Through bore | 8 mm |
| Pole pairs | 14 |
| Ingress protection | IP45 |
Who makes it
MakerCubeMars
Based inChina
RoleBrand owner
CubeMars and T-MOTOR are one manufacturer group (Sanrui Intelligent, Nanchang, Jiangxi), already in Maglev's actuator benchmark pool as CN002; contact on file is info@cubemars.com. Ask about custom windings and which country each part is made in.
Landed cost in the US
Loading duty data…
Compliance
| HTS classification | unknown |
|---|---|
| NDAA | unknown |
| Blue UAS | unknown |
| FCC | n/a |
| Notes | Store SKU AJD05010003 (no encoder). |
Equivalents from other makers
Works with
Sources
- https://www.cubemars.com/product/gl40-kv70-gimbal-motor.htmlspecs table, 2D/3D drawing downloads
- https://store.cubemars.com/products/gl40-kv70price $72.99 (no encoder) / $97.99 (encoder), SKU AJD05010003, rated/peak torque, 107 g
Record confidence: VERIFIED. VERIFIED means the maker's own documents; REPORTED means a credible third party; UNVERIFIED means a single weak source. Anything we could not confirm says unknown.
